Specifications |
|
|
| |
|
|
General |
| |
|
|
CPU: |
|
On-board NS Geode GX1 300MHz |
| |
|
|
CPU Chipset: |
|
NS CS5530A |
| |
|
|
Bios: |
|
AWARD |
| |
|
|
System Memory: |
|
One SO-DIMM socket, supports 128MB SDRAM memory maximum |
| |
|
|
Watchdog: |
|
Software programmable 1~63 seconds |
| |
|
|
I/O Chip with RTC: |
|
Winbond W83977F standard RTC |
| |
|
|
Serial Port: |
|
One RS-232C and one RS-232C/RS-485 COM port |
| |
|
|
Parallel Port: |
|
One parallel port, support SSP/EPP/ECP modes |
| |
|
|
Enhanced IDE: |
|
Supports one Enhanced IDE port up to two Enhanced IDE devices
(Ultra DMA 33 mode) |
| |
|
|
FDD interface: |
|
Supports one FDC port up to two FDDs |
| |
|
|
IrDA Port: |
|
Provides the function of IrDA 1.1 (MIR for 1.152M bps or FIR for 4M bps) |
| |
|
|
USB: |
|
Supports two USB connectors, USB 1.0 compliant |
| |
|
|
Keyboard and mouse: |
|
PS/2 connector for keyboard and mouse |
| |
|
|
PC/104 expansion: |
|
104-pin 16-bit PC/104 module connector |
| |
|
|
VGA Display |
| |
|
|
Chipset: |
|
NS CS5530A on-chip VGA |
| |
|
|
Display memory: |
|
Shared system memory 1~4MB |
| |
|
|
Interface: |
|
CRT/LCD/LVDS |
| |
|
|
Audio |
| |
|
|
Audio: |
|
AC97 ver 2.0 compliant with audio I/O, Mic in, and CD audio in |
| |
|
|
LAN |
| |
|
|
Chipset: |
|
Realtek RTL8139C |
| |
|
|
Interface: |
|
Supports 10/100Mbps Base-T with RJ-45 connector built-in LED |
| |
|
|
Solid State Disk |
| |
|
|
Solid State Disk: |
|
Supports one Compact Flash Interface and one DOC socket |
| |
|
|
Mechanical and Environmental |
| |
|
|
Power Requirement: |
|
+5V-3.0A |
| |
|
|
Operating Temp: |
|
0~60°C |
| |
|
|
Operating Humidity: |
|
0~90°C Relative humidity non-condensing |
| |
|
|
Storage Temp.: |
|
20~80°C |
| |
|
|
PC Board: |
|
8 layers |
| |
|
|
Dimensions: |
|
145mm x 102 mm (5.7" x 4") |
| |
|
|
| |
|
|
